2M KABLO

Your Connection to Life...

2MKAB NGF FE180 PH30 2x2.5 mm² LPCB 7111/01

Used in fixed applications, switch board or subscriber systems. Depending on the applications need, PVC or HFFR outer sheathed, with bare or tinned copper conductor, screened or unscreened types are available. HFFR versions are less flammable in case of fire, mostly self extinguishing, have low smoke density and they do not emit poisonous and corrosive gasses during fire. Fire alarm cables are used in internal and external places such as schools, hospitals, meeting rooms and shopping centers where safety regulations must be taken into consideration against fire. These cables can be preferred in communication, ventilation, lighting and voice announce systems of emergency exit ways, equipments and devices. Screened types protect the signal from electromagnetic interference and provide continuity in signal quality.

Constructional Properties

Conductor:

Insulation:

Core Identification:

Lay-up:

Seperator:

Overall Screen:

Sheath:

Cable Color:

Solid annealed copper wire (Class 1)

Silicone Rubber

Refer to the table below

Cores stranded in layers

PET Foil

AL/PET Foil + Solid Tinned Copper Drain Wire | x 0.8 mm

Halogen Free Flame Retardant Compound (HFFR/LSZH/LSOH/FRNC)

RAL3000-Red

Technical Properties (20°C)

Operating Voltage:

Test Voltage:

Operating Temp. Fixed:

Installation Temperature:

Flame Propagation:

Smoke Density:

Corrosive Gases:

Fire Resistance:

Min. Bending Radius:

300/500 V

2kV

-30°C...+70°C

0°C...40°C

IEC 60332-1-2, IEC 60332-3-24

IEC 61034-1/2

IEC 60754-1/2

IEC 60331-21, EN 50200 (PH30), BS 6387 (C, W, Z)

10 x Cable Diameter
